B7018-E-T-P4S-UL

Engineered to meet the stringent demands of high-performance machine tool spindles, the FAG B7018-E-T-P4S-UL is a high-precision angular contact ball bearing built for maximum structural rigidity and operational accuracy. This specific model features a 90mm bore and a 140mm outer diameter, employing a 25-degree contact angle to efficiently handle combined radial and heavy axial loads. By incorporating larger steel rolling elements than standard high-speed variants, the B7018-E-T-P4S-UL excels in maintaining system stiffness under heavy cutting forces, while its resin-laminated fabric cage ensures smooth guidance and stable lubricant distribution at elevated velocities. Precision-ground to FAG's P4S tolerance standard-which exceeds conventional DIN 620 P4 requirements-the B7018-E-T-P4S-UL minimizes thermal expansion and micro-vibrations during prolonged operating cycles. Additionally, the universal design with a light preload configuration means that each B7018-E-T-P4S-UL can be easily paired or stacked in custom duplex or multiplex arrangements without sacrificing its baseline tolerance characteristics or running efficiency.

We provide sea and air freight services for large bearings, and international express shipping services for small bearings.
