51260-MP Bearing
Size: 300*420*95 mm
Weight: 43.2 kg
Number of Row: Singel row
Situation: In stock
Leading time: 3-6 working days
Contact: info@bearingmotion.com
|
51260-MP bearing |
|
|
Type |
Thrust Ball Bearing |
|
Bore diameter (d) |
300 mm |
|
Outside diameter(D) |
420 mm |
|
Width（B） |
95 mm |
|
Basic dynamic load rating, axial（Ca） |
590000 N |
|
Basic static load rating,axial（C0a） |
2700000 N |
|
Fatigue load limit, axial（Cua） |
64000 N |
|
Limiting speed（nG） |
970 1/min |
|
Reference speed(nϑr) |
1150 1/min |
|
Mass |
43.2 KG |
Products Description
51260-MP Bearings are composed of three parts: seat ring, shaft ring, and steel ball retainer. The shaft ring is the part that fits with the shaft, while the seat ring fits with the housing.
51260-MP Bearings are designed to withstand thrust loads when operating at high speeds. They consist of a washer-like sleeve with grooves for ball rolling. Due to the shape of the sleeve, thrust ball bearings are divided into flat seat type and self-aligning spherical seat type. Additionally, these bearings can withstand axial loads but not radial loads.
