7026AC Bearing
Size: 130*200*33 mm
Weight: 3.43 kg
Number of Row: Singel row
Situation: In stock
Leading time: 3-6 working days
Contact: info@bearingmotion.com
|
Type |
Angular Contact Ball Bearings |
|
Model |
7026AC |
|
Inside diameter (d) |
130 mm |
|
Outer diameter (D) |
200 mm |
|
Width (B) |
33 mm |
|
D1 |
178.4 mm |
|
d1 |
151.6 mm |
|
Basic dynamic load rating |
140 kN |
|
Basic static load rating |
150 kN |
|
Fatigue load limit |
4.9 kN |
|
Limiting speed |
3400 r/min |
|
Reference speed |
2600 r/min |
|
Mass |
3.43 kg |
Application for 7026AC Bearing:
These super-precision, high-capacity, single row angular contact ball bearings, with 25° contact angle, accommodate radial and axial loads acting simultaneously, where the axial load acts in one direction only. They are designed to accommodate heavy loads at relatively high speeds under low to moderate operating temperatures.
