GN104KRRB + COL Locking Collar Ball Bearing
Size: 80*38.1*22 mm
Weight: 0.86 kg
Situation: In stock
Number of Row: Single Row
Leading time: 3-6 working days
Contact: info@bearingmotion.com
|
GN104KRRB + COL Locking collar ball bearing |
|
|
Type |
Locking Collar Ball Bearing |
|
Outside Diameter D |
80 mm |
|
Inner Ring Width B |
38.1 mm |
|
Outside Ring Width C |
22.0 mm |
|
Radius r |
0.6 mm |
|
Center of Bearing from End S |
18.3 mm |
|
Set Screw Size |
5/16-18 |
|
Number of Set Screws |
2 |
|
Angle between Set Screws |
90 º |
|
Dimension d1 |
55.6 mm |
|
Dimension M |
3.96 mm |
|
Dimension B1 |
51.6 mm |
|
Dimension B2 |
17.5 mm |
|
Mass |
0.86 KG |
Products Description
The GN104KRRB + COL locking collar ball bearing is a versatile and reliable component used in various industrial applications. This type of bearing is designed with a locking collar that provides a secure fit and prevents the bearing from slipping on the shaft. The locking collar also allows for easy installation and removal, making it a convenient choice for maintenance and repair processes.
The GN104KRRB + COL locking collar ball bearing is constructed with high-quality materials and precision engineering, ensuring its durability and long-lasting performance. It is capable of handling heavy loads and high speeds, making it suitable for demanding operational conditions.
Products Details
Warehouse Display
Client Comment
The GN104KRRB + COL locking collar ball bearing has received positive feedback from our client. This product has proven to be reliable and efficient in various applications. The locking collar feature ensures secure attachment, providing peace of mind to our customers. We are pleased to receive such commendations and will continue to provide high-quality products and excellent service to meet the needs of our clients.
