7313 BECBF

7313 BECBF

size:65*140*33mm
weight:2.34 kg
Single row angular contact ball bearing
A one-year warranty is provided under normal operating conditions.
WhatsApp:+8618753115023
E-mial:info@bearingmotion.com
Send Inquiry
Chat Now
Product Introduction

Products Description

Bore diameter 65 mm
Outside diameter 140 mm
Width 33 mm
Contact angle 40 °
Basic dynamic load rating 108 kN
Basic static load rating 80 kN
Reference speed 6 300 r/min
Limiting speed 5 600 r/min
Product net weight 2.34 kg

7313 BECBF bearing

Product Related

Designed specifically for high-speed industrial operations, the 7313 BECBF single row angular contact ball bearing excels at managing simultaneous radial and one-directional axial loads. This premium component features a optimized 40° contact angle alongside a robust machined steel cage, making the 7313 BECBF significantly more capable of handling intense unilateral thrust forces than standard deep groove alternatives. With a standard 65 mm bore, 140 mm outer diameter, and 33 mm width, its universal matching design allows for seamless mounting in pairs without complicated clearance adjustments. Built from high-purity bearing steel, the 7313 BECBF delivers minimal operational friction and high rotational stability, allowing machinery to sustain reference speeds up to 6,000 r/min while extending service life under demanding factory conditions.

bearing type

transportation

We provide sea and air freight services for large bearings, and international express shipping services for small bearings.
